Consew Model 733R-5

733R-5
Consew Model 733R-5

Overview

Extra Heavy Duty, Long Arm, Single Needle, Drop Feed, Alternating, Presser Feet, Lockstich Machine.

With: Extra Large, Long Beak, Oscillating Shuttle Hook and Bobbin, Extra High Foot Lift - (1-1/4" / 32mm), Two Row Feeder, Reverse Feed

Applications

  • For stitching extra heavy-weight materials
  • Designed for such operations and products as safety and logging belts, cargo slings, buffing wheels, tents, sails, harnesses, tarpaulins and covers, fabric structures, construction barriers, parachutes, balloons, industrial bags, boot stitching, book binding

Features

  • Syncronized upper and lower feeding mechanism assures uniform stitching
  • Alternating presser feet
  • Steel insert for take-up hinge
  • Reverse stitching - hand or foot operated
  • Stitch regulator - hand or foot operated
  • Presser foot lift - hand or foot operated
  • 1-1/4 inch presser foot lift
  • Two row feeder
  • Two stitches to the inch
  • Stitches per minute - 550
  • Extra large, long-beak oscilating shuttle, hook and bobbin
  • Belt guard

ADDITIONAL INFORMATION

Specifications

Number of Needles 1 (Single)
Feeding Mechanism Walking Foot
Workspace Standard Workspace
Standard or Full Function Standard Functions
Speed, Max (S.P.M.) 550
Clearence Under Presser Foot 1 1/4" (32mm)
Stitch Length 2 s.p.i. (13mm)
Hook Size Large
Work Space 16 1/4" (413mm)
Needle 1000 or 1000H
Bobbin Pre-Wound 41
Bed Size 10" x 26 1/4" (258mm x 665mm)
Stitch Type 301
Gross Weight 348 lbs. (158 kgs)
Weight 231 lbs. (105kg)
Needle Bar Stroke 2 3/32" (53mm)
Hook 35224
