Consew Model 3321 series

3321 series

Overview

Models 3321, 3322, 3323, 3324, 3325, 3326:  with 1 to 6 needles.      Optional Puller: 332x-P

High Speed, Drop Feed, Needle Feed (Compound Feed), Walking Presser Foot, Double Chainstitch Machine

With: Fully Automatic Lubrication, Simplified Looper Throw-out, Safety Balance Wheel



Applications

  • For sewing medium to heavy weight fabrics such as vinyl, leather, canvas, denim, synthetics and various coated and laminated materials
  • Suitable,for stitching operations on such products as awnings, tents, tarpaulins, auto, marine and furniture- upholstery, auto interiors, auto tops, handbags, luggage, belts, curtains, draperies, bed spreads, blankets, bathing trunks, boxer shorts, trousers, uniforms, walking shorts, jackets, work clothes, slippers, women's shoes, canvas shoes, sports equipment, carpets, mattresses, mattress pads, gloves and numerous other articles
  • Machines can be used for seaming, binding, welting, banding, bibbing, lap seam felling and taping with appropriate attachments

Features

  • Fully automatic lubrication with recirculating pump
  • Simplified looper throw-out
  • Easy accessibility for threading loopers
  • Compound feed, walking foot mechanism ensures even feeding of article being sewn
  • No bobbin winding or changing
  • Attachments easily installed
  • Configurations:
    # Needles       Model      with Puller      Spec. Large Stitch
    1 Single           3321          3321-P             3321-S
    2 Two               3322          3322-P             3322-S
    3 Three            3323          3323-P             3322-S
    4 Four              3324          3324-P             3324-S
    5 Five               3325          3325-P             3325-S
    6 Six                 3326          3326-P             3326-S

ADDITIONAL INFORMATION



Specifications

Number of Needles 1 thru 6
Feeding Mechanism Walking Foot
Workspace Standard Workspace
Standard or Full Function Standard Functions
Speed, Max (S.P.M.) up to 4000
Stitch Type 401
Max Stitch Length 3 s.p.i. (8.5mm)
Needle Bar Stroke 1 11/32" (34mm)
Needle Used 62 x 59
Work Space 10 5/8" (270mm)
Bed Size 7" 20 3/8" (177mm x 518mm)
Looper 20301
Clearance Under Foot 5/16" (8mm)
Needle Distances 3/16" (4.7mm) - 2" (50.8mm)
Number of Threads 1 - 6 dep. on needles
